The SAM3X has 512 KB (2 blocks of 256 KB) of flash memory for storing code. A properly configured shield can read the IOREF pin voltage and select the appropriate power source or enable voltage translators on the outputs for working with the 5V or 3.3V. This pin on the Arduino board provides the voltage reference with which the microcontroller operates. This regulator also provides the power supply to the SAM3X microcontroller. A 3.3 volt supply generated by the on-board regulator. Supplying voltage via the 5V or 3.3V pins bypasses the regulator, and can damage your board. The board can be supplied with power either from the DC power jack (7 - 12V), the USB connector (5V), or the VIN pin of the board (7-12V). This pin outputs a regulated 5V from the regulator on the board. You can supply voltage through this pin, or if supplying voltage via the power jack, access it through this pin. The input voltage to the Arduino board when it's using an external power source (as opposed to 5 volts from the USB connection or other regulated power source). If using more than 12V, the voltage regulator may overheat and damage the board.
If supplied with less than 7V, however, the 5V pin may supply less than five volts and the board may be unstable. The board can operate on an external supply of 6 to 20 volts. Leads from a battery can be inserted in the Gnd and Vin pin headers of the POWER connector. The adapter can be connected by plugging a 2.1mm center-positive plug into the board's power jack. The power source is selected automatically.Įxternal (non-USB) power can come either from an AC-to-DC adapter (wall-wart) or battery.
The Arduino Due can be powered via the USB connector or with an external power supply.
Flash Memory 512 KB all available for the user applications.Total DC Output Current on all I/O lines 130 mA.Digital I/O Pins 54 (of which 12 provide PWM output).a DMA controller, that can relieve the CPU from doing memory intensive tasks.(for more information look int type page). A 32-bit core, that allows operations on 4 bytes wide data within a single CPU clock.The Due has a 32-bit ARM core that can outperform typical 8-bit microcontroller boards. An unconnected pin, reserved for future use.This enables shield compatibility with a 3.3V board like the Due and AVR-based boards which operate at 5V. The IOREF pin which allows an attached shield with the proper configuration to adapt to the voltage provided by the board.TWI: SDA and SCL pins that are near to the AREF pin.The Due is compatible with all Arduino shields that work at 3.3V and are compliant with the 1.0 Arduino pinout. The board contains everything needed to support the microcontroller simply connect it to a computer with a micro-USB cable or power it with a AC-to-DC adapter or battery to get started. Providing higher voltages, like 5V to an I/O pin could damage the board. The maximum voltage that the I/O pins can tolerate is 3.3V. Warning: Unlike other Arduino boards, the Arduino Due board runs at 3.3V.
ARDUINO ARM CORTEX SERIAL
It has 54 digital input/output pins (of which 12 can be used as PWM outputs), 12 analog inputs, 4 UARTs (hardware serial ports), a 84 MHz clock, an USB OTG capable connection, 2 DAC (digital to analog), 2 TWI, a power jack, an SPI header, a JTAG header, a reset button and an erase button. It is the first Arduino board based on a 32-bit ARM core microcontroller. The Arduino Due is a microcontroller board based on the Atmel SAM3X8E ARM Cortex-M3 CPU (datasheet). Arduino Due R3 Arduino Due Rev3 (Atmel SAM3X8E ARM Cortex-M3 32-bit MCU)
